Viewing Status and Statistics This chapter explains how to use ADU to view the client adapter's status and its transmit and receive statistics. The following topics are covered in this chapter:. Overview of ADU Status and Statistics Tools In addition to enabling you to configure your client adapter for use in various types of networks, ADU provides tools that enable you to assess the performance of the client adapter and other devices on the wireless network. These tools perform the following functions:. Display your client adapter's current status and configured settings. Display statistics pertaining to your client adapter's transmission and reception of data enables you to quickly find instructions for using ADU status and statistics tools.

Table 7-1 Status and Statistics Tool Instructions Tool Page Number Status Statistics Setting Parameters that Affect ADU Status and Statistics Tools Several parameters affect the operation of ADU status and statistics tools. Follow these steps to set these parameters.

Step 1 Open ADU. Step 2 Choose Display Settings from the Options drop-down menu. The Display Settings window appears (see ). Figure 7-1 Display Settings Window Step 3 lists and describes the parameters that affect the operation of ADU status and statistics tools. Follow the instructions in the table to change any parameters. Table 7-2 Parameters Affecting ADU Status and Statistics Tools Parameter Description Signal Strength Display Units Specifies the units used to display signal strength on the Advanced Status and Available Infrastructure and Ad Hoc Networks windows. Options:% or dBm Default: dBm Units Description% Displays the signal strength as a percentage.

DBm Displays the signal strength in decibels with respect to milliwatts. Refresh Interval Specifies how often the ADU status and statistics windows and the ASTU icon are updated. Range: 1 to 5 seconds between updates (in 1-second increments) Default: 3 seconds between updates Data Display Specifies whether the data that is displayed on the Diagnostics and Advanced Statistics windows continue to increment until the driver is reloaded or only until an update occurs (every 1 to 5 seconds). Options: Relative or Cumulative Default: Cumulative Data Display Description Relative Displays statistical data collected since the last update, as specified by the Refresh Interval (1 to 5 seconds). Cumulative Displays statistical data collected since the driver was loaded, upon card insertion or reboot.

Step 4 Click OK to save your changes. Viewing the Current Status of Your Client Adapter ADU enables you to view the current status of your client adapter as well as many of the settings that have been configured for the adapter. To view your client adapter's status and settings, open ADU. The Current Status window appears (see ). Figure 7-2 Current Status Window interprets each element of the Current Status window.

Table 7-3 Basic Client Adapter Status Status Description Profile Name The network configuration (or profile) your client adapter is currently using. Note Refer to for information on creating, modifying, and selecting profiles. Link Status The operational mode of your client adapter. Value: Not Associated, Associated, Authenticating, Authenticated, Authentication Failed, Authentication Failed Retrying Link Status Description Not Associated The client adapter has not established a connection to an access point (in infrastructure mode) or another client (in ad hoc mode). Associated The client adapter has established a connection to an access point (in infrastructure mode) or another client (in ad hoc mode). Authenticating The client adapter is associated to an access point, and the EAP authentication process has begun but not yet succeeded.

Authenticated The client adapter is associated to an access point, and the user is EAP authenticated. Authentication Failed The client adapter is associated to an access point, but the user has failed to EAP authenticate. Authentication Failed Retrying The client adapter is associated to an access point, the user has failed to EAP authenticate, but another authentication attempt is being made. Server Based Authentication The method by which authentication to a back-end server is being performed to establish secure connectivity. Value: None, LEAP, EAP-TLS, PEAP (EAP-GTC), or PEAP (EAP-MSCHAP V2) Note Refer to the for details on these server-based authentication types.

Cisco aironet 802.11 a b g driver for mac free

Data Encryption The data encryption type that was negotiated with the access point (in infrastructure mode) or another client (in ad hoc mode) upon association. Value: None, WEP, CKIP, or TKIP Note Refer to the for details on these data encryption types. Network Type The type of network in which your client adapter is being used.

Value: Infrastructure or Ad Hoc Note Refer to the Network Type parameter in for information on setting the network type. Current Channel The channel that your client adapter is currently using for communications. This field displays Scanning while the client adapter searches for a channel. Value: Dependent on radio band and regulatory domain Note Refer to the Channel parameter in for information on setting the channel for your client adapter. Note Refer to for a list of channel identifiers, channel center frequencies, and regulatory domains for each channel. Wireless Mode The frequency and rate at which your current wireless connection is capable of transmitting or receiving packets.

Cisco Aironet 802.11 A B G Driver For Mac

Value: 5 GHz 54 Mbps, 2.4 GHz 11 Mbps, or 2.4 GHz 54 Mbps Note Refer to the Wireless Mode parameter in for information on setting the wireless mode for your client adapter. IP Address The IP address of your client adapter.

Signal Strength The signal strength for all received packets. The color of this parameter's progress bar provides a visual interpretation of signal strength.

Value: Excellent (green), Good (green), Fair (yellow), Poor (red), or No Link Click Advanced if you want to view more detailed status information for your client adapter. The Advanced Status window appears (see ). Figure 7-3 Advanced Status Window interprets each element of the Advanced Status window. Table 7-4 Advanced Client Adapter Status Status Description Network Name (SSID) The name of the network to which your client adapter is currently associated. Note Refer to the SSID1 parameter in for information on setting the client adapter's SSID. Server Based Authentication The method by which authentication to a back-end server is being performed to establish secure connectivity.

Value: None, LEAP, EAP-TLS, PEAP (EAP-GTC), or PEAP (EAP-MSCHAP V2) Refer to the for details on these server-based authentication types. Data Encryption The data encryption type that was negotiated with the access point (in infrastructure mode) or another client (in ad hoc mode) upon association. Value: None, WEP, CKIP, or TKIP Note Refer to the for details on these data encryption types. Authentication Type Specifies whether the client adapter must share the same WEP keys as the access point in order to authenticate or can authenticate to the access point regardless of its WEP settings.

Value: Open or Shared Note An incorrect WEP key setting prevents connectivity to the network regardless of the 802.11 authentication type selected. Note Refer to the for information on setting the 802.11 authentication mode. Message Integrity Check Indicates whether your client adapter is using message integrity check (MIC) to protect packets sent to and received from the access point. MIC prevents bit-flip attacks on encrypted packets. During a bit-flip attack, an intruder intercepts an encrypted message, alters it slightly, and retransmits it, and the receiver accepts the retransmitted message as legitimate. Note MIC is supported automatically by the client adapter's driver, but it must be enabled on the access point.

Value: None, MMH, or Michael Message Integrity Check Description None MIC is disabled. MMH MIC is enabled and is being used with CKIP. Michael MIC is enabled and is being used with WPA and TKIP. Associated AP Name The name of the access point to which your client adapter is associated. It is shown only if the client adapter is in infrastructure mode, the access point was configured with a name, and Aironet Extensions are enabled (on access points running Cisco IOS Release 12.2(4)JA or later). Note This field shows up to 15 characters although the name of the access point may be longer.

Associated AP IP Address The IP address of the access point to which your client adapter is associated. It is shown only if the client adapter is in infrastructure mode, the access point was configured with an IP address, and Aironet Extensions are enabled (on access points running Cisco IOS Release 12.2(4)JA or later). Note If Aironet Extensions are disabled, the IP address of the associated access point is shown as 0.0.0.0.

Associated AP MAC Address The MAC address of the access point to which your client adapter is associated. It is shown only if the client adapter is in infrastructure mode. Note This field displays the MAC address of the access point's Ethernet port (for access points that do not run Cisco IOS software) or the MAC address of the access point's radio (for access points that run Cisco IOS software). The MAC address of the Ethernet port on access points that run Cisco IOS software is printed on a label on the back of the device. Power Save Mode The client adapter's current power consumption setting. Value: CAM (Constantly Awake Mode), Max PSP (Max Power Saving), or Fast PSP (Power Save Mode) Note Refer to the Power Save Mode parameter in for information on setting the client adapter's power save mode. Current Power Level The power level at which your client adapter is currently transmitting.

The maximum level is dependent upon the radio band used and your country's regulatory agency. Value: 10, 20, 30, 50, 63, or 100 mW (802.11b/g band); 10, 13, 20, 25, or 40 mW (802.11a band) Note Refer to the Transmit Power Level parameter in for information on setting the client adapter's power level. Available Power Levels The power levels at which your client adapter is capable of transmitting. The maximum level is dependent upon the radio band used and your country's regulatory agency. Value: 10, 13, 20, 25, or 40 mW (802.11a); 10, 20, 30, 50, 63, or 100 mW (802.11b/g) Note Refer to the Transmit Power Level parameter in for information on the client adapter's available power levels. Current Signal Strength The signal strength for all received packets.

The higher the value, the stronger the signal. Range: 0 to 100% or 0 to -100 dBm Current Signal Quality The signal quality for all received packets. The higher the value, the clearer the signal. Range: 0 to 100% Note This setting appears only if you selected signal strength to be displayed as a percentage. See the Signal Strength Display Units parameter in for information. Current Noise Level The level of background radio frequency energy in the current radio band. The lower the value, the less background noise present.

Range: 0 to -100 dBm Note This setting appears only if you selected signal strength to be displayed in dBm. See the Signal Strength Display Units parameter in for information. Up Time The amount of time (in hours:minutes:seconds) since the client adapter has been receiving power.

If the adapter has been running for more than 24 hours, the time is displayed in days, hours:minutes:seconds. 802.11b Preamble Indicates whether your client adapter is using only long radio headers or short and long radio headers. Value: Short & Long or Long Only Note This field contains a value only when the client adapter is operated in 2.4-GHz 11-Mbps or 2.4-GHz 54-Mbps mode. Note Refer to the 802.11b Preamble parameter in for information on using radio headers. Current Link Speed The rate at which your client adapter is currently transmitting data packets. Value: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, or 54 Mbps Channel The channel that your client adapter is currently using for communications.

This field displays Scanning while the client adapter searches for a channel. Value: Dependent on radio band and regulatory domain Note Refer to the Channel parameter in for information on setting the channel for your client adapter. Note Refer to for a list of channel identifiers, channel center frequencies, and regulatory domains for each channel. Frequency The radio frequency that your client adapter is currently using for communications. This field displays 'Scanning' while the client adapter searches for a frequency.

Value: Dependent on radio band and regulatory domain Note Refer to the Wireless Mode parameter in for information on setting the frequency for your client adapter. Channel Set The regulatory domain for which your client adapter is currently configured. This value is not user selectable. Value: America, EMEA, Japan, or Rest of World Note Refer to for a list of channel identifiers, channel center frequencies, and regulatory domains for each channel.

Click OK to close the Advanced Status window. Viewing Statistics for Your Client Adapter ADU enables you to view statistics that indicate how data is being received and transmitted by your client adapter. To view your client adapter's statistics, open ADU and click the Diagnostics tab. The Cisco Aironet Desktop Utility (Diagnostics) window appears (see ). Figure 7-4 Cisco Aironet Desktop Utility (Diagnostics) Window This window displays basic transmit and receive statistics for your client adapter. The statistics are calculated on a relative or cumulative basis as specified by the Data Display parameter and are continually updated at the rate specified by the Refresh Interval parameter.

Instructions for changing the Data Display and Refresh Interval settings are provided in. Note The receive and transmit statistics are host statistics. That is, they show packets and errors received or sent by the Windows device. Describes each statistic that is displayed for your client adapter. Table 7-5 Basic Client Adapter Statistics Statistic Description Transmit Statistics Multicast Packets The number of multicast packets that were transmitted. Broadcast Packets The number of broadcast packets that were transmitted. Unicast Packets The number of unicast packets that were transmitted successfully.

Total Bytes The number of bytes of data that were transmitted successfully. Receive Statistics Multicast Packets The number of multicast packets that were received. Broadcast Packets The number of broadcast packets that were received. Unicast Packets The number of unicast packets that were received successfully. Total Bytes The number of bytes of data that were received successfully. Click Advanced Statistics if you want to view additional statistics for your client adapter.

Cisco Aironet 802.11 A B G Driver For Mac Pro

Cisco aironet 802.11 a b g driver for mac pro

The Advanced Statistics window appears (see ). Figure 7-5 Advanced Statistics Window interprets each element of the Advanced Statistics window.

Table 7-6 Advanced Client Adapter Statistics Status Description Transmit Statistics Frames Transmitted OK The number of frames that were transmitted successfully. Frames Retried The number of frames that were retried. Frames Dropped The number of frames that were dropped because of errors or collisions. No ACK Frames The number of transmitted frames that did not have their corresponding Ack frame received successfully. ACK Frames The number of transmitted frames that had their corresponding Ack frame received successfully. RTS Frames The number of request-to-send (RTS) transmissions that were attempted. CTS Frames The number of clear-to-send (CTS) frames that were received in response to a successfully transmitted RTS frame.

No CTS Frames The number of request-to-send (RTS) transmissions that were unsuccessful. Retried RTS Frames The number of request-to-send (RTS) frames that were retransmitted. Retried Data Frames The number of normal data frames that were retransmitted. Receive Statistics Beacons Received The number of beacon frames that were received successfully.

Frames Received OK The number of all frames that were received successfully. Frames Received with Errors The number of frames that were received with an invalid checksum. CRC Errors The number of cyclic redundancy check (CRC) errors detected in the data portion of the frame. Encryption Errors The number of frames that were received with encryption errors. Duplicate Frames The number of duplicate frames that were received. AP Mismatches The number of times the client adapter tried to associate to an access point but was unable to because the access point was not the adapter's specified access point.

Note Refer to the Access Point 1 through Access Point 4 parameters on for information on specifying access points. Data Rate Mismatches The number of times the client adapter tried to associate to an access point but was unable to because the adapter's data rate was not supported by the access point.

Note Refer to the Wireless Mode parameter in for information on supported data rates. Authentication Time-Out The number of times the client adapter tried to authenticate to an access point but was unable to because the access point did not respond fast enough (timed out). Authentication Rejects The number of times the client adapter tried to authenticate to an access point but was rejected. Association Time-Out The number of times the client adapter tried to associate to an access point but was unable to because the access point did not respond fast enough (timed out). Association Rejects The number of times the client adapter tried to associate to an access point but was rejected. Standard MIC OK The number of frames that were received with the correct message integrity check (MIC) value. Standard MIC Errors The number of frames that were discarded due to an incorrect message integrity check (MIC) value.

CKIP MIC OK The number of frames that were received with the correct message integrity check (MIC) value when CKIP was being used. Note This field is displayed only if MIC is enabled on the access point. CKIP MIC Errors The number of frames that were discarded due to an incorrect message integrity check (MIC) value when CKIP was being used.

Cisco Aironet 802.11 A B G Driver For Mac Free

Note This field is displayed only if MIC is enabled on the access point. Click OK to close the Advanced Statistics window.
